Automatic Crimping Machine For Cable Ferrules

technical data:total length: 210 mmstripping area (min. - max.) (awg): 28 -5working range: 0.08 - 16 mm2weight: 545 g.catalog no.: 41246ean: 4010995412463automatic crimp tool for wire-end ferrules hexagonal crimpfor clean cable termination. Wiha 41246automatic crimping pliers with hexagonal crimp help prevent unnecessary damage to cables and wire-end ferrules. they feature a wide crimping range of 0.08–16 mm2 and compactly combine the functions of two pliers in one making them suitable for most applications. the hexagonal crimp prevents cable ferrules from snagging. the insertion function provides additional process safety by preventing crimping of the plastic sheath of the cable ferrule. thanks to the automatic crimping function these pliers are suitable for both hollow sleeves (up to 16 mm2) and twin sleeves (up to 10 mm2). flexible and shock-absorbing plastic handles ensure comfortable work reducing fatigue. the built-in lever allows you to manually interrupt the crimping process at any time.application:for processing cable ferrules with or without insulating collar according to din 46228 en 50027**the presented photos are for illustrative purposes only
